Composition of cryogenic storage tanks

After the cryogenic storage tank is filled, the internal pressure is generally maintained at about 0.25~0.35MPa

Content

This type of cryogenic storage tank usually does not have a boiler drum. The heating surface is composed of multiple groups of pipe rows and headers. It has a compact structure, is easy to manufacture and install, and consumes less steel. Its heating surface layout methods include downstream, countercurrent and mixed flow.
