Cryogenic micro storage tank

Content

Micro storage tank is a storage tank used to store cryogenic liquid, which can be used to store liquid oxygen, liquid natural gas, etc. It integrates fixed base, cryogenic storage tank, cryogenic liquid filling and self-pressurized gasification system.The storage tank is a double-layer structure design, the inner container is S30408 stainless steel, the outer shell is Q245R, and the middle interlayer is made of high-vacuum multi-layer winding, which can ensure the sealing of the storage tank and avoid the entry of external heat, which is the medium in the storage tank.So that the microbulk tank can provide the best storage environment.The cryogenic micro storage tank is one of our company main product and it is very popular in many diffferent countries and fields.It’s very convenient and portable，easy to operate,less footprint,if you want have your own tank，welcome you send inquiry to us.

Inquiry
