External inspection of pressure vessels

Content

The main contents of external inspection (also known as in-operation inspection) are: whether there are abnormal phenomena such as cracks, deformation, leakage, local overheating, etc. on the outer surface of the pressure vessel; whether the safety accessories are complete, sensitive, and reliable; whether the fastening bolts are intact and tightened; whether the foundation sinks, tilts, and whether the anti-corrosion layer is damaged.
