Gasification station valve

Naturally set gas temperature drop alarm at the outlet of the vaporizer

Pipeline valves use special stainless steel valves for LNG manufactured in accordance with API standards.

Content

The use of special low-temperature valves should meet the LNG delivery pressure (pressure level PN1.6Mpa) and flow requirements, and have low-temperature resistance (-196°C). It mainly includes: special long-axis stop valve, short-axis stop valve, three-way valve, safety valve, check valve, boost regulating valve and pipeline pressure control valve, etc. It also includes pneumatic low-temperature valves: emergency shut-off valve, etc.

Inquiry
